Processor Processor frequency 3.2 GHz Processor family 8th gen Intel® Core™ i7 Processor model i7-8700 Processor cores 6 Number of processors installed 1 Processor boost frequency 4.6 GHz Processor socket LGA 1151 (Socket H4) Processor cache 12 MB Processor cache type Smart Cache Processor threads 12 System bus rate 8 GT/s Bus type DMI3 Processor lithography 14 nm Processor operating modes 64-bit Processor series Intel Core i7-8700 Desktop Series Processor codename Coffee Lake Thermal Design Power (TDP) 65 W Tjunction 100 °C PCI Express slots version 3.0 Maximum number of PCI Express lanes 16 PCI Express configurations 1x16,1x8+2x4,2x8 Maximum internal memory supported by processor 64 GB Memory types supported by processor DDR4-SDRAM Memory clock speeds supported by processor 2666 MHz Memory bandwidth supported by processor (max) 41.6 GB/s ECC supported by processor No Memory Internal memory 8 GB Internal memory type DDR4-SDRAM Maximum internal memory 64 GB Memory layout (slots x size) 2 x 4 GB Memory slots 4x DIMM Memory clock speed 2666 MHz Non-ECC Yes Memory channels Dual Storage Total storage capacity 256 GB Storage media SSD Number of SSDs installed 1 SSD capacity 256 GB SSD interface Serial ATA III Graphics Discrete graphics adapter No On-board graphics adapter Yes Discrete graphics adapter model Not available On-board graphics adapter model Intel® UHD Graphics 630 On-board graphics adapter family Intel® UHD Graphics On-board graphics adapter base frequency 350 MHz On-board graphics adapter dynamic frequency (max) 1200 MHz Maximum on-board graphics adapter memory 64 GB Number of displays supported (on-board graphics) 3 On-board graphics adapter DirectX version 12.0 On-board graphics adapter OpenGL version 4.5 On-board graphics adapter ID 0x3E92 Number of execution units 24 Optical drive Optical drive type DVD±RW Optical drives quantity 1 Network Ethernet LAN Yes Wi-Fi No Ethernet LAN data rates 10,100,1000 Mbit/s Cabling technology 10/100/1000Base-T(X) Ports & interfaces USB 2.0 ports quantity 4 USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 5 USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity 1 DVI port No Ethernet LAN (RJ-45) ports 1 Microphone in No Headphone outputs 1 PowerShare Yes Number of USB ports with PowerShare support 2 DisplayPorts quantity 2 PS/2 ports quantity 2 Line-out Yes Combo headphone/mic port Yes Total number of SATA connectors 4 On/off button Yes Expansion slots PCI Express x1 slots 1 PCI Express x16 slots 2 PCI slots 1 Design Product colour Black Chassis type Tower Volume 14.77 L Placement supported Vertical Number of 3.5" bays 1 Number of 5.25" bays 2 Cable lock slot Yes Cable lock slot type Kensington Performance Product type PC Market positioning Business Motherboard chipset Intel Q370 Compatible processor series Intel® Core™ i3, Intel Core i5, Intel Core i7 Audio chip Realtek ALC3234 Trusted Platform Module (TPM) Yes Dell E-Value Code N032O7060MTBTPDEAT Software Operating system installed Windows 10 Pro Operating system architecture 64-bit Operating system language Multilingual Trial software Microsoft Office Processor special features Intel 64 Yes Enhanced Intel SpeedStep Technology Yes Embedded options available No Intel® InTru™ 3D Technology Yes Intel® Clear Video HD Technology (Intel® CVT HD) Yes Intel Clear Video Technology Yes Intel VT-x with Extended Page Tables (EPT) Yes Intel TSX-NI Yes Idle States Yes Thermal Monitoring Technologies Yes Intel Stable Image Platform Program (SIPP) Yes Intel® AES New Instructions (Intel® AES-NI) Yes Intel® Secure Key Yes Intel® OS Guard Yes Intel Trusted Execution Technology Yes Execute Disable Bit Yes Intel Enhanced Halt State Yes Intel Software Guard Extensions (Intel SGX) Yes Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) Yes Processor package size 37.5 x 37.5 mm Supported instruction sets AVX 2.0,SSE4.1,SSE4.2 Processor code SR3QS Scalability 1S CPU configuration (max) 1 Thermal solution specification PCG 2015C Intel Virtualization Technology for Directed I/O (VT-d) Yes Intel Virtualization Technology (VT-x) Yes Processor ARK ID 126686 Intel® Turbo Boost Technology 2.0 Intel® Hyper Threading Technology (Intel® HT Technology) Yes Intel® Quick Sync Video Technology Yes Intel® Identity Protection Technology (Intel® IPT) Yes Conflict Free processor Yes Power Power supply 200 W Power supply input voltage 90 - 264 V Certificates RoHS compliance Yes Energy Star certified Yes Certification TCO, CEL, WEEE Weight & dimensions Width 154 mm Depth 274 mm Height 350 mm Weight 7.93 kg Packaging data Package width 494 mm Package depth 394 mm Package height 335 mm Package weight 9.43 kg Packaging content Display included No Mouse included Yes Mouse included on selected markets only Yes Keyboard included Yes Keyboard included on selected markets only Yes Keyboard language German Cables included AC Manual Yes Power cord included Yes

The desktop reimagined

OptiPlex has 25 years of experience delivering customer-led innovation for desktops by continuously adapting to the way you work. Now featuring versatile, space-saving form factors and 8th generation Intel® Processors to unleash your full potential.

Designed to tackle the workday

Compact without compromise: With full-power features in a space-saving design, more workers choose the OptiPlex micro than ever before. The micro takes up less surface area while still maintaining all the reliability you've come to expect.

Mount it and forget it: With exclusive custom mounting options, including the VESA mount or the OptiPlex Micro All-in-One Stand, the micro adapts to your unique environment, giving you the freedom to work how you want.

Powerful productivity

Power your success: With 8th generation Intel® Core™ Processors, every business task is a breeze. Intel® Optane™ Memory turns even the smallest, routine tasks into huge productivity gains, launching browsers and opening files faster and smoother than ever.

Connect with ease: Support up to three monitors with two native DisplayPorts and optional third port. Choose from third DisplayPort, HDMI 2.0b, VGA, or USB Type-C Alt Mode. Support additional monitors with discrete graphics options.

Smooth, speedy performance: Advanced PCIe NVMe drives provide a blazing-fast boost to data access times.

OptiPlex 7060 Micro with Intel Unite®

Smoother collaboration. Smarter meetings: Transform any room into a secure, modern meeting space with Intel Unite® software for better communication among teams, including real-time sharing, annotation and file transfers. Users can connect, share and display with a split-screen view, mark-up shared content, and drag and drop files with ease.

Secure

Because security starts with best-in class hardware, the OptiPlex micro features TPM 2.0 and a chassis intrusion switch. Add custom cable covers and a security lock to protect your investment. Plus, Dell Data Security offers comprehensive threat protection from end-to-end, so you can focus more on your work and spend less time worrying about your system.

Manageable

The Dell Client Command Suite automates and streamlines system deployment, configuration, monitoring and updates and is free on all Dell commercial PCs.

Reliable

Your system will withstand real world conditions thanks to a durable, built-to-last chassis that’s undergone MIL-STD 810G testing. A simple removable side panel allows for quick system access to easily upgrade and replace components like storage and memory, making your PC viable for years to come.
