Features Cable length 3 m Connector 1 DisplayPort Connector 2 DisplayPort Connector 1 gender Male Connector 2 gender Male Maximum resolution 3840 x 2400 pixels Product color Black Connector 1 form factor Straight Connector 2 form factor Straight Connector contacts plating Nickel DisplayPort version 1.2 Supported graphics resolutions 3840 x 2400, 2560 x 1600 (WQXGA) Maximum refresh rate 120 Hz HDCP Yes DisplayPort Content Protection (DPCP) Yes Latching connectors Yes Cable rating CMG (CM) Cable shielding Aluminum mylar foil Jacket material Polyvinyl chloride (PVC) AWG wire size 28 Bandwidth 21600 MB/s Plug and Play Yes Multi-Stream Transport (MST) Yes Number of conductors 19 Certificates Compliance certificates RoHS Weight & dimensions Cable diameter 7.3 mm Weight 210 g Packaging data Package width 200 mm Package depth 220 mm Package height 34 mm Package weight 215 g Packaging content Quantity per pack 1 pc(s) Logistics data Harmonized System (HS) code 84733080 Master (outer) case width 330 mm Master (outer) case length 500 mm Master (outer) case height 280 mm Quantity per master (outer) case 50 pc(s)

Create high-resolution 4K x 2K connections with HBR2 support between your DisplayPort equipped devices

This DisplayPort cable provides a secure connection between your DisplayPort equipped devices and is capable of providing higher performance than either HDMI® or dual-link DVI.

The DP cable supports high resolutions of up to 4K x 2K (4096 x 2160, 60Hz) with a maximum HBR2 bandwidth of 21.6Gbps, as well as optional audio support. The cable also supports Multi-Stream Transport (MST) for daisy chaining multiple monitors.

The 10-foot cable is DisplayPort (VESA) certified to support DP 1.2 specifications and ensure a high-quality, reliable connection for all of your DisplayPort devices.

The DISPLPORT10L is backed by a StarTech.com lifetime warranty for guaranteed reliability and ensures that digitally protected content is displayed properly, with both HDCP and DPCP capability.
