Features Cable length 0.122 m Connector 1 DisplayPort Connector 2 HDMI Type A (Standard) Connector 1 gender Male Connector 2 gender Female Connector 1 form factor Straight Connector 2 form factor Straight HDMI version 2.0b HDCP Yes HDCP version 2.2 DisplayPort version 1.4 DisplayPort Content Protection (DPCP) Yes High Dynamic Range (HDR) supported Yes Maximum resolution 4096 x 2160 pixels Supported graphics resolutions 3840 x 2160, 4096 x 2160 Data transfer rate 18 Gbit/s Maximum refresh rate 60 Hz Product colour Black Chipset MegaChips - MCDP2900 Supported audio channels 7.1 Plug and Play Yes Operational conditions Operating temperature (T-T) 5 - 35 °C Storage temperature (T-T) -20 - 60 °C Operating relative humidity (H-H) 25 - 60% Certificates Compliance certificates RoHS Certification CE, FCC Weight & dimensions Weight 25 g Width 253 mm Depth 29 mm Height 11 mm Packaging data Package width 200 mm Package depth 220 mm Package height 12 mm Package weight 46 g Packaging content Quantity per pack 1 pc(s) Logistics data Harmonized System (HS) code 84733080 Master (outer) case width 330 mm Master (outer) case length 500 mm Master (outer) case height 220 mm Products per master (outer) case 120 pc(s) Other features Material Plastic

DisplayPort™ 1.4 Video Adapter | Ultra HD | Up to 18Gbps

This DisplayPort to HDMI Adapter lets you connect your DP equipped computer to an HDMI display. The adapter supports High Dynamic Range (HDR) and provides sharper images with enhanced video.

With brighter colors and greater contrast, the adapter is ideal for:

• Creating eye-catching visuals for photography, videography, cinematography

• Displaying crisp digital signage walls

• Delivering enriched presentations

True 4K at 60Hz and HDR

The DisplayPort to HDMI adapter is fully compatible with your HDMI 2.0b equipment, supporting resolutions up to 4K 60Hz (3840 x 2160) and bandwidths up to 18Gbps. The adapter offers 4:4:4 chroma subsampling, so every pixel gets its own unique color. It’s also backward compatible with earlier versions of HDMI and DisplayPort at their supported maximum resolutions.

With HDR support, you can enjoy lifelike images with increased contrast, brightness and colors and greater luminosity than standard digital imaging.

Ideal for Travel

This lightweight video adapter is highly portable, with a small footprint design. It's the perfect accessory for your DP supported devices, fitting easily into your carrying case.

Hassle-Free Setup

To ensure easy operation and installation, this unique DP to HDMI adapter allows for plug-and-play installation without any additional software or drivers.

DP2HD4K60H is backed by a 3-year StarTech.com warranty and free lifetime technical support.

Notes:

• To achieve HDR, your DisplayPort device must support version 1.4 and your display must support HDMI 2.0b.
• NVIDIA graphics adapters may not support 4:4:4 chroma subsampling and 5.1/7.1 audio output, when used with this adapter.

The StarTech.com Advantage
